Mode selection pin. Connected in parallel with the
onboard MD button. Use an open collector circuit
to control this line as pressing the MD button
short-circuits the line onto the GND.
Leave this pin unconnected.
PLL control line (HIGH- PLL ON, LOW- PLL OFF).
Red status LED control line. Also connected to the
onboard LED. Maximum load on this line is 3mA.
Use a buffer (logic gate) if higher current is
desired.
Green status LED control line. Also connected to
the onboard LED. Maximum load on this line is
3mA. Use a buffer (logic gate) if higher current
is desired.
General-purpose I/O line 46.
General-purpose I/O line 45 (does not belong to
any 8-bit port);
square wave output line.
General-purpose I/O line 48 (does not belong to
any 8-bit port).
General-purpose I/O line 47 (does not belong to
any 8-bit port).
RX line of debug serial port (details to be
published).
Output of the onboard 3.3V regulator. Can supply
up to 1A of current to external devices (1.3A
without the WA2000).
This line can also be used to power the EM1001.
Use regulated 3.3V power source only!
TX line of debug serial port (details to be
published).
Switching regulator supply voltage in the 8-20V
range. The regulator generates 3.3V power for the
onboard circuitry, WA2000, and external devices
connected to the 3.3V line.
There is no need to use this input if the EM1001 is
powered directly through the 3.3V line.
This line is also connected to the positive terminal
on the power jack.
3.3V power available on this pin. Do not connect
to the power source.
General-purpose I/O line 49 (does not belong to
any 8-bit port).
General-purpose I/O line 50 (does not belong to
any 8-bit port).
