6Embedded Modules
© Tibbo Technology Inc.
EM1000TEV and EM1000EV development systems (they are compatible with the
EM2000 module). The EM2000 can also support Wi-Fi and GPRS communications.
EM2000 advantages over the EM1000 module
The EM2000 is a high-performance upgrade to our EM1000 device. Here is small list
of important improvements:
·
32-bit architecture (vs. 16-bit architecture of the EM1000).
·
5 to 80 times better performance, depending on the calculations and variable
types.
·
7 times faster GPIO manipulation.
·
3 times larger available user SRAM (66KB vs. 22KB).
·
1.5-3.0 times faster graphics.
·
2.2 times lower power consumption (100mA vs. 220mA).
·
2 times larger flash memory (1MB for TiOS/code + 1MB for the file system vs. 1MB
total for TiOS, code, and file system).
·
56 I/O lines (vs. 54 lines on the EM1000).
·
4-channel ADC.
·
The ability to update TiOS firmware and compiled Tibbo BASIC/C app over-the-air
(this requires the WA2000 and an iOS or Android device).
Hardware features
·
32-bit architecture.
·
Powered by Tibbo OS (TiOS).
·
10/100BaseT auto-MDIX Ethernet port (automatic detection of "straight" and
"cross" cables). Standard Ethernet magnetics are NOT integrated into the module.
·
Optional Wi-Fi interface (requires the WA2000 add-on module to be connected).
·
Optional BLE interface (requires the WA2000 add-on module).
·
Can control a GPRS modem* (such as the SIM900).
·
Four high-speed serial ports (CMOS-level):
- Baudrates of up to 460,800bps;
- None**/even/odd/mark/space parity modes;
- 7**/8 bits/character;
- Full-duplex mode with RTS/CTS and XON/XOFF flow control;
- Half-duplex mode with direction control;
- Encoding and decoding of Wiegand and clock/data streams.
·
56 general-purpose I/O lines; 8 lines can work as interrupts.
·
Square wave output (can be used for buzzer* control).
·
4-channel ADC.
·
4 synchronous serial ports with SPI and I2C modes.
·
Supports a 320x240 TFT LCD*.
·
Supports matrix and binary output keypads*.
