The EM2000EV board incorporates the following:
·
Two 15x2 and one 6x2 female sockets (shown in gray) for plugging in the EM2000
IoT module (not included with the EM2000EV).
·
Two additional 15x2 female sockets (shown in black) located on the sides of the
EM2000. Each pin on these sockets is connected to a corresponding pin on the
EM2000's socket.
·
Power jack and a 3.3V switching power supply. The nominal input voltage is 12V.
·
Ethernet port — RJ45 jack with magnetics.
·
MD button.
·
Three LEDs:
§
SR (status red) and SG (status green) LEDs connected to SR and SG lines of
the EM2000;
§
EY (Ethernet yellow) LED connected to the EY line of the EM2000.
