Notes:
Standard EM2000 devices do not have a wireless add-on connector (a.k.a. "SPI
port") and the "landing" PCB area for the connector is left empty (cross-section A).
Compatible wireless add-on modules (such as the WA2000 Wi-Fi module) can
optionally be soldered into the connector pads (cross-section B).
Option "-A" EM2000 devices feature a 10-pin wireless add-on header (cross-section
C). The pins on this header are identical to all other pins of the EM2000 and face
the host PCB. This way the wireless add-on port of the EM2000 can be connected
to some other circuitry on the host PCB. For example, instead of mounting onto the
EM2000, the WA2000 add-on can be mounted directly onto the host PCB. Option "-
A" EM2000 module is then required to facilitate the connection between the EM2000
and the wireless add-on.
Finally, option "-T" devices have a female wireless add-on port connector, which the
WA2000 can be plugged into. EM2000 modules of "-T" variety (cross-section D) are
intended for convenient testing of wireless modules and are not recommended for
use in production devices.
L
Max
.
38.
4
Module length
W
Max
.
28.
4
Module width
H
Max
.
5.5
Module height
H
'
Max
.
11.
0
Module height with the WA2000 module soldered into the
EM2000 module
h
Max
.
4
Additional height added by the supercapacitor ("-S" option
devices only)
I
Min
.
6.0
Lead length
p
Ave
r.
2.5
4
Pin pitch
Dimensions are for reference only. Tibbo assumes no responsibility for any errors in
this Manual, and does not make any commitment to update the information
contained herein.
