Tibbo EM1000 User Manual

472External Controllers
© Tibbo Technology Inc.
of an additional serial channel. Don't want CTS and RTS either? That's one more
channel! In total, there are 15 different configurations to choose from.
The DS1202 is fully supported by TIDE software and a dedicated DS1202 platform
that covers all hardware facilities of the device (see TIDE, TiOS, Tibbo BASIC, and
Tibbo C Manual). This product ships preloaded with a fully functional serial-over-IP
application. Written in Tibbo BASIC, the application is compatible with Tibbo Device
Server Toolkit software, comes with full source codes, and can be modified by the
user.
Hardware features
· Superior upgrade to the DS203 devices.
· Based on the EM1202 BASIC-programmable embedded module.
· 100BaseT auto-MDIX Ethernet port (automatic detection of "straight" and "cross"
cables).
· Up to 3.5 serial channels on a single RS232 connector:
- Baudrates of up to 921,600bps;
- None/even/odd/mark/space parity modes;
- 7/8 bits/character modes;
- Optional flow control;
- Flexible mapping with 15 different options, such as:
- A single channel: RX, TX, CTS, RTS, DSR, and DTR lines;
- 3.5 channels: RX, TX, RX2, TX2, RX3, TX3, and RX4 lines.
· 1024KB flash memory for firmware, application, and data storage.
· 2KB EEPROM for data storage.
· Six LEDs:
- Green and red status LEDs on top of the device;
- Green and red status LEDs on the RJ45 jack;
- Link and speed Ethernet status LEDs on the RJ45 jack.
· Software-controlled onboard PLL to select the clock frequency of the device:
11.0592MHz with PLL off, 88.4736MHz with PLL on.
· Supply voltage range: 10-24V (12V nominal).
· Dimensions: 60x47x30mm.
· Firmware and Tibbo BASIC/C application are upgradeable through the serial port or
network.
· Tibbo BASIC/C application can be debugged through the network and no additional
debugging hardware, such as in-circuit emulator, is required.
· Also available as a EM1202EV (board without housing).
Programming features
· Variable Types: Byte, char, integer (word), short, dword, long, real, string, plus
user-defined arrays and structures.
· Function Groups: string functions (27 in total!), date/time conversion functions
(8), encryption/hash calculation functions (AES128, RC4, MD5, SHA-1), and more.
· Platform objects:
- Sock — socket communications (up to 16 UDP, TCP, and HTTP sessions);
