544Monitor/Loader (M/L)
© Tibbo Technology Inc.
The diagram below shows the EM2000 device, but the same arrangement can be
used for all boards and modules.
Ethernet Updates
Ethernet firmware upgrades are supported by the Monitor/Loader of the following
Tibbo devices: EM500, EM510, EM2000, EM2001, TPP2(G2), and TPP3(G2). This
means that not every Tibbo device with an Ethernet port supports Ethernet
firmware upgrades from the M/L.
Prerequisites
To perform an Ethernet upgrade:
·
You must have the firmware file you will be sending into your device. There are
two possibilities:
o You may upload just a TiOS firmware file (.bin). All TiOS firmware is published
here: http://tibbo.com/support/downloads/tios.html.
o You may upload a TiOS firmware file combined with a compiled application
binary. You can produce such combined files using our online tool found at
http://apps.tibbo.com/bin_merger/ or using our legacy BinMerger utility
(http://tibbo.com/support/downloads/tide.html).
·
You must connect your Tibbo device to the same Ethernet LAN segment with your
PC:
o EM2001, TPP2(G2), and TPP3(G2) devices have the RJ45 Ethernet jack.
o EM500, EM510, and EM2000 require an Ethernet front-end (magnetics and RJ45)
to be connected externally. If your EM500, EM510, or EM2000 module is "on its
