Compact dimensions, innovative space-saving "vertical slice" mechanical design, low
power consumption, and patented dual-function LED control lines make the module
an excellent fit for miniature, cost-sensitive IoT designs.
The EM510 is fully supported by TIDE software and a dedicated EM510 platform that
covers all hardware facilities of the device (see TIDE, TiOS, Tibbo BASIC, and Tibbo
C Manual). For convenient testing and evaluation Tibbo offers the EM510EV
development system.
The EM510 can be ordered standalone or in combination with an industry-standard
RJ45 jack and other discrete components required to complete a working circuit.
EM510 advantages over the EM500 module
The EM510 is a higher-performance upgrade to our EM500 device. Here is a small list
of important improvements:
· 32-bit architecture (vs. 8-bit architecture of the EM500).
· 17 to 33 times better performance, depending on the calculations and variable
types.
· 8 times faster GPIO manipulation.
· 2.3 times lower power consumption (110mA vs. 260mA).
· Added support for BLE (Bluetooth Low Energy) communications (this requires the
WA2000 add-on).
· Added suppport for WPA and WPA2 Wi-Fi security modes (Wi-Fi communications
rely on the WA2000 add-on).
· SSI (SPI and I2C communications) object included.
· The ability to update TiOS firmware and compiled Tibbo BASIC/C app over-the-air
(this requires the WA2000 and an iOS or Android device).
· 20
o
C lower internal running temperature (52
o
C vs. 73
o
C).
· Industrial operating temperature range (-40 ~ +85C).
Hardware features
· 32-bit architecture.
· Powered by Tibbo OS (TiOS).
· 10/100BaseT auto-MDIX Ethernet port (automatic detection of "straight" and
"cross" cables). Standard Ethernet magnetics are NOT integrated into the module.
· Optional Wi-Fi interface (requires the WA2000 add-on module to be connected).
· Optional BLE (Bluetooth Low Energy) interface (requires the WA2000 add-on
module to be connected).
· One serial port (CMOS-level):
- Baudrates of up to 460,800bps;
- None*/even/odd/mark/space parity modes;
- 7*/8 bits/character;
- Full-duplex mode with RTS/CTS and XON/XOFF flow control;
- Half-duplex mode with direction control;
- Encoding and decoding of Wiegand and clock/data streams.
