BASIC ANALYZER OPERATION
Chapter 4
............
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 155 © Veolia 2023
► Selecting the Integral value will display a graph of that Repetition to the left
of the screen.
• Calibration Status Indicator — This is an indication if the Calibration is currently
being used can be enabled by the User. The label on the button changes to
display different Calibration statuses.
► “Activate” means this Calibration is not currently being used but can be
selected by the User.
► “Active” means the Calibration is currently being used for Analysis. See
Figure 4-49 on page 154
.
► “Rejected” Integral appear unselectable or “grayed out”.
• Reference — this indicates if the Calibration was set up as a Reference
Calibration. NOTE: This will only be visible if the Calibration was marked as
Reference.
• Slope — slope calculated based on the calculated average.
• Injections and Dilution — parameters configured and used for the highlighted
Calibration.
• Zero — the calculated or forced Y-intercept based on Calibration Method and
results.
MENU → GENERAL
This menu displays the General/Global Analyzer settings
Use the General screen to access the following sub-menus:
• “System Settings” on page 156
• “Info” on page 158
• “Machine Configuration” on page 158
• “Time/Date Settings” on page 160
• “Software” on page 160
• “Ethernet” on page 161
