CARRIER GAS
. . . .. . . ... .... .... .... ..... ..
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 32 © Veolia 2023
• 1 or 2 sample streams (Second Stream is purchasable option)
• Optional: “ECD Detector” for TNb Detection or “PID Detector” for POC/VOC Detection
2
• Optional: Communication Box
• Optional: Air Box
• Optional: Air Scrubber
• Optional: Particulate Sampler
• Optional: Mounting Rack
ADDITIONAL SYSTEM AND OPERATING SPECIFICATIONS
Carrier Gas
Requirements: CO
2
-Free: < 1ppm CO
2
.
Hydrocarbon Free: < 0.1 ppm, moisture and particle
free as per ANSI 7.0.01 for instrument air.
Moisture free and particle free.
Options*: Nitrogen, Zero/Synthetic Air, Plant Instrument Air**,
or Air Box Accessory.
Pressure: 100-200 kPa (1-2 Bar, 14.5-29 psig)
Flow Rate: Continuous; 30-50 LPH; Regulated to 20-30 LPH.
Connection Type: Press Fit — 6 mm OD, 4 mm ID
*If using an external air connection, there must be an appropriate Pressure
Regulator (Maximum of 100 kPa,1 bar, 14.5 psig) and Shut-off Valve
installed near the Analyzer location.
**If using Plant Instrument Air, the Analyzer will require the Air Scrubber
Accessory.
Reagent
Acid Type: Analytical Method and Sample Dependent;
Acid Selection and Concentration is based on the
sample and Analytical Method used.
1. Typical Sample Time is Sample and Analytical Method dependent.
2. The Analyzer cannot be configured with both optional Detectors.
