INSTALLATION
Chapter 3
............
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 61 © Veolia 2023
Shipping List:
• Sievers TOC-R3
• Installation Guide
• Operation and Maintenance Manual (accessed from the Sievers website).
► For more information, see page 2
.
• Certificate of Calibration
• Shipping Kit; located inside the Analyzer cavity for shipping. Contains the
provided items for install. Be careful when handling! Several items are fragile!
Table 3-1: Shipping List
Item
Name Qty.
1 Sievers TOC-R3 1 --
2 Furnace Sleeve* 1
3 Furnace Cartridge* 1
4 Furnace Ceramic Packing Set* 1
5 Furnace Cartridge Support Plate* 1
6 Furnace Head Cover*
(With attached Furnace Head
Compression Fitting [10])
1
7 Isoplan High Temperature Gasket
(50x38x2) (Small Inner Diameter /
ID)
1
