FLOW PATH COMPONENTS
. . . .. . . ... .... .... .... ..... ..
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 42 © Veolia 2023
Thick, dark Blue lines represent Sample flow path.
Black, dashed lines indicate waste lines.
Flow Path Components
B1NDIR Detector. See “B1 NDIR Detector (for CO
2
Detection)” on page 42.
B2 — (Optional) ECD Detector or PID Detector
See “B2 — ECD Detector Option (for NO Detection)” on page 43
.
See “B2 — PID Detector Option (for POC/VOC Detection)” on page 44
Sensors — BF1, BF2, BP1, and BP2. See “Sensors” on page 45.
CM1 — Injection Accumulator. See “CM1 — Injection Accumulator” on page 45.
CM2 — Multi-Function Sample Vessel (MFSV). See “CM2 — Multi-Function
Sample Vessel” on page 46.
EB1 — Furnace. See “EB1 — Furnace” on page 46.
EC1 — Gas Cooler Unit. See “EC1 — Gas Cooler Unit” on page 46.
Pumps: GP1, GP2, GP3, and GP4. See “Pumps” on page 46.
Filters: HS1, HS2, HS3, HS4. See Filters” on page 47.
KH1 — Pressure Regulator. See “KH1 — Pressure Regulator” on page 47.
MFSV VentOpen to atmosphere. See MFSV Vent” on page 48.
RM1 — Check Valve. See RM1 — Check Valve” on page 48.
Nozzles — RN1 and RN2. See Nozzles” on page 48.
Valves: Y1, Y2, Y3, Y4, Y5, Y6, Y7, Y9, Y10, Y11, and Y12. See “Valves” on
page 48.
B1 — NDIR Detector (for CO
2
Detection)
The Analyzer uses catalyst-free, high temperature combustion oxidation and Non-
Dispersive Infrared (NDIR) (B1) detection to measure a wide range of CO
2
, carbon
concentrations in complex sample matrices, including those containing high
concentrations of Total Dissolved Solids (TDS) and particulates. During the signal
integration phase, the NDIR signal rises as the measuring peak occurs and then
decreases as CO
2
is carried out of the NDIR Detector.
The NDIR Detector Analytical Range is specific to the hardware installed. This is
determined during product planning and custom installed individually per Customer
requirements. If there is a change in the sample location, the installed NDIR Detector can
be changed in the field. For more information, please contact Sievers Technical Support
or your Local Service Provider.
The "raw" NDIR Detector signals are displayed as “CO
2
in ppm” and the concentrations
are displayed in “mg/L”.
