Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 30 © Veolia 2023
CHAPTER 2: SYSTEM DESCRIPTION
SYSTEM SPECIFICATIONS
2SHUDWLQJ6SHFL¿FDWLRQV
Analytical Methods Standard: TC, NPOC
Option: TIC, TOCdiff, POC/VOC*, TNb*
Ranges TC/Carbon
: 0-10; 0-200; 0-2,000; 0-10,000; with Dilution 0-50,000 mg/L;
Wide Range: 0-200; 200-20,000 mg/L;
TNb*: 0-150 and 0-1,500 mg/L;
POC/VOC*: 0-25 mg/L;
Options/Accessories Leak Detection (for TC only), Sample Stream 2, Particulate Sampler, Air Box,
Air Scrubber, Communication Box, Moun
ting Rack, PID Detector* (for POC/VOC)
or ECD Detector* (for TNb)
Features Auto Calibration, Dilution, Check Function, Auto Rinse, Connectivity
(Remote Control), Predictive Maintenance
Precision +/-2% End of Detector Range†
Linearity R² 0.997†
LOD <1 ppm†
Analysis Time 3-5 min typically
Smallest Inner Diameter (ID) 2 mm smallest tubing diameter
Salt Tolerance 3-5% NaCl
Carrier Gas CO๜free air < 1 ppm CO๜and < 0.1 ppm hydrocarbon: 100-200 kPa
@ 30-50 l/hÀow r
ate (Optional: Air Box)
Sample Temperature 2-60 °C (35.6-140 °F)
Ambient Temperature 2-40 °C (35.6-104 °F)
Minimum Sample Flow Rate 100 mL/min without Particulate Sampler or 11.7-50 LPM (3.1-13.2 US gal/min)
with Particulate Sampler
Drain Gravity, No back pressure (< 7 kPa, 0.07 Bar, 1 psig)
$QDO\]HU6SHFL¿FDWLRQV
Communication Protocols OPC-UA, Modbus TCP/IP
Inputs Digital Input (4)
Display 7 in. Touch panel
Power AC 110-230 V ±10 V, 50/60 Hz, 400-600 VA
Outputs
Ethernet, 0/4-20 mA (6), Programmable Digital Relay (4)
Installation/Overvoltage Category II
Available Configurations Standard: Single-Stream; Option: Second Stream
Dimensions 900 H x 644.3 W x 354.5 D mm (35.5 H x 25.4 W x 14 D in)
Weight 55 kg (121 lb)
Safety CerWL¿Fations CE, UL, CSA
Regulatory DIN EN 1484 /ISO 8245, EPA 415.3, SM 5310B, ASTM D5173, HJ 501,
DIN EN 12260
(QYLURQPHQW
Enclosure Standard: IP-54; Option: ATEX Zone 1 & 2 T4, IECEx Zone 1 & 2 T4, C1D2
Maximum Relative Humidity Up to 85%, non-condensing
†Stated analytical performance achieved under ideal laboratory conditions using 0-10 mg/L NDIR Detector.
* Requires the purchase of an Optional Detector; either PID Detector (for POC/VOC) or ECD Detector (for
TNb).
The Analyzer cannot be configured with both purchasable Detectors.
