DIMENSIONS AND LOCATIONS
Appendix A
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 243 © Veolia 2023
Furnace Foot, Below the Furnace
Figure A-14: Furnace Foot, Below the Furnace
95loc006
Thumb Screw
Furnace Foot
Z-Bracket
Furnace Foot
Assembly
Transfer Tube
Transfer Tube Port
