FURNACE HEAD ASSEMBLY, EXPLODED
. . . .. . . ... .... .... .... ..... ..
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 242 © Veolia 2023
Furnace Head Assembly, Exploded
Figure A-13: Furnace Head Assembly, Exploded
95loc008
Ferrule
Injection Block
Compression Fitting
Furnace Head
Compression Fitting
Compression Nut
Injection Needle
Compression Nut
Ferrule
Ferrule
Ferrule
Isoplan High Temperature
Gasket
Furnace Head
Cover
