Installing an Ethernet Connection (Optional)
Ethernet connectivity is available for:
• Exporting historical data from the Analyzer to a computer, computer Network, or
Programmable Logic Controller (PLC).
To install an Ethernet cable
Provide an Ethernet cable.
1. Attach one end of the Ethernet cable to the Ethernet Port (Port 10)
on the bottom of
Analyzer enclosure. See Figure 3-3 on page 65
.
2. Attach the other end of the cable to an Ethernet port on a local network or computer.
3. After installing the Ethernet cable, enable and configure the Ethernet connection in
the Analyzer’s firmware. For more information, see “Configuring the Ethernet
Connection (Optional)” on page 91..
NOTE: The Analyzer’s USB Port is not designed for Ethernet connectivity
(using an Ethernet to USB adapter). For acceptable uses of the USB Port, refer
to the section “Using the USB Port” on page 106.
Configuring the Ethernet Connection (Optional)
Use this instruction to enable the Ethernet connection and set up a manual (fixed) IP
address or an automatic (dynamic) IP address.
After configuring the Ethernet connection:
• To collect data, use a third-party data acquisition software or a SCADA system
with Modbus TCP/IP to support the collection of real-time instrument data and
status information. For more information, refer to “Modbus Configuration” on
page 262.
NOTE: You may need to consult with your remote operations center to
determine some of the values.
To configure an Ethernet connection
This process may be completed now or at a later time.
1. Navigate to the following: Menu → General → Ethernet
