DIMENSIONS AND LOCATIONS
Appendix A
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 233 © Veolia 2023
Air Box and Air Scrubber Dimensions
Figure A-6: Air Box and Air Scrubber Dimensions
Ø102
Ø90
M2ϱĐĂďůĞĐŽŶŶĞĐƟŽŶ
2x M1ϲĐĂďůĞĐŽŶŶĞĐƟŽŶ
Plug
95inst006
158.84 mm
6.25 in
240 mm
9.5 in
220 mm
8.7 in
299.66 mm
11.8 in
120 mm
4.2 in
15 mm
0.6 in
130 mm
5.12 in
264.32 mm
10.4 in
268 mm
10.6 in
