WETTED MATERIALS
. . . .. . . ... .... .... .... ..... ..
Sievers TOC-R3 Operation and Maintenance Manual
DLM 95000-01 EN Rev. A 50 © Veolia 2023
Sample Inlet Valve Group (Y1
Y4)
Manifold
Valve Body
Valve Membrane
Fitting UNF
PEEK
PEEK
FKM
PEEK
Sample Pump (GP1) Tube Novoprene
Sample Injection Valve Group
(Y5Y7)
Manifold
Valve Body
Valve Membrane
Fitting UNF
PEEK
PEEK
FKM
PEEK
Furnace (EB1) Injection Needle
Furnace Head
Seal – Head
Furnace Cartridge
a
Ceramic Disk
Upper Furnace Foot
Lower Furnace Foot
Seal – Bottom
Transfer Tube Fitting
Hastelloy®
Macor®
FKM
Al
2
O
3
Al
2
O
3
Al
2
O
3
PEEK
Creaflon® / PTFE
PTFE
Multi-Function Sample Vessel
(CM2)
Glass
Seal
Connection Bottom
Fitting UNF
Tube Outlet 1
Tube Outlet 2
Tube Air 1
Tube Air 2
Borosilicate
PTFE
PTFE
PEEK
Silicone
Marprene®
PVC
Marprene®
Gas Cooler Unit (EC1) Tube Air inlet
Seal
Crew Connection
Tube Air
PTFE
FKM
PTFE
Viton® / FKM
Condensate Pump (GP2) Tube
Y-Connector
Tube - Pump
Viton® / FKM
PP
Marprene®
a. And internal contents.
Table 2-5: Wetted Materials List (Continued)
Module Part Material
