Xerox Phaser 6180 - Drive Assembly

Phaser 6180 Color Laser Printer Service Manual 2-67
Theory of Operation
Drive Assembly
The Drive Assembly transmits drive energy as shown in the following diagram.
Paper Handling
Process
s6180-299
[Name of Moving Parts]
Drive Assembly
Tray 2 Motor
Tray 1 (MPT) Feed Solenoid
Tray 1 (MPT) Gear
[Tray 1 (MPT) Roller]
Tray 1 (MPT)
Turn Clutch Registration Clutch
[Turn Roller]
[Rubber Registration Roller]
Rubber Registration Gear
Metal Registration Gear
[Metal Registration Roller]
Feeder
Feed Clutch
Oneway Nudger Clutch
[Feed Roller]
[Feed Roller]
Nudger Idler Gear
Nudger Roller Gear
