Xerox Phaser 6180 - Tray 2 Retard Roll (PL2.2.17)

Phaser 6180 Color Laser Printer Service Manual 33
Service Parts Disassembly
Tray 2 Retard Roll (PL2.2.17)
1. Remove Tray 2.
2. Release the hooks on the left and right of the Retard Tray Cover
(PL2.2.13) and open the Retard Tray Cover.
3. Release the hooks on the left and right side of the Retard Roll and
remove the Retard Roll from the Retard Shaft (PL2.2.15).
s6180-060
