Xerox Phaser 6180 - Extender Cover (PL1.1.9)

18 Phaser 6180 Color Laser Printer Service Manual
Service Parts Disassembly
Extender Cover (PL1.1.9)
1. Open the Extender Cover.
2. Press the center part of the Extender Cover and pull one of the two
notches of the Extender Cover from the hole of the Top Cover (PL1.1.1).
3. Pull out the other notch of the Extender Cover from the hole of the Top
Cover and remove the Extender Cover.
s6180-006
