Xerox Phaser 6180 - Fuser Error

3-36 Phaser 6180 Color Laser Printer Service Manual
Error Messages and Codes
Fuser Error
The Fuser temperature regulation has failed.
W
arn
i
ng
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
Applicable Chain Link
■ Chain Link 010-397: Fuser Error
Initial Actions
■ Ensure that the Fuser latches are fully locked.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting References
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser, PL6.1.10
■ Fuser Harness, PL6.1.11
■ Top LV Harness, PL10.1.16
■ LVPS, PL9.1.4
■ MCU Board, PL9.1.20
■ “Map 1 - Electrical and Drive” on
page 10-10
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Fuser” on page 10-46
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the Fuser for correct installation. Go to step 2. Reseat the
Fuser. Go to
step 2.
2 Does the error still occur? Go to step 3. Complete.
3 Check the wiring harness connectors P/J17,
P/J171, P/J47, P/J501, and P/J14. Are the
connectors securely connected?
Go to step 4. Reconnect
the
connectors.
4 Check the Fuser Harness for continuity.
1. Disconnect P/J17 and P/J171.
2. Check continuity between P/J17 <=> P/
J171.
Go to step 5. Replace the
Fuser
Harness.
