4-8 Phaser 6180 Color Laser Printer Service Manual
General Troubleshooting
Printer Components
Motors, Clutches, Solenoids, Lamps
HVPS
OHP Sensor LED
Main Motor
Black
Toner Motor
Yellow
Toner Motor
Magenta
Toner Motor
Cyan
Toner Motor
Black
Erase Lamp
Yellow,
Magenta,
Cyan
Erase Lamp
Tray 2
Feed Clutch
Regi Clu
t
ch
MPT Turn Clutch
MPT Feed Solenoid
Exit Clutch
Tray 3 Turn Clutch
Fan
ADC Sensor
Solenoid
ADC Sensor LED
Sub Motor
Deve Motor
Tray 2 Motor
Tray 3 Feed Clutch
Tray 3 Feed Motor
s6180-361
