Phaser 6180 Color Laser Printer Service Manual 10-7
Plug/Jack and Wiring Diagrams
Duplex Plug/Jack Designators
Duplex Plug/Jack Designators
P/J Map Coordinates
Remarks
1 5 E-168 Not connected (Debug only).
J427 5 F-168 Connects Duplex Board and Duplex Fan.
J428 5 F-168 Connects Duplex Board and Duplex Unit Harness.
J429 5 F-169 Connects Duplex Board and Duplex Motor.
J430 5 F-168 Connects Duplex Board and Duplex Sensor
Harness.
J431 5 F-168 Connects Duplex Board and Duplex Clutch.
J2720 5 I-169 Connects Duplex (Duplex Unit Harness) and printer.
J4301 5 E-167 Connects Duplex Jam Sensor and Duplex Sensor
Harness.
