Xerox Phaser 6180 - Consumable;Routine Maintenance Procedures; Insert Fuser

3-32 Phaser 6180 Color Laser Printer Service Manual
Error Messages and Codes
Consumable/Routine Maintenance Procedures
Insert Fuser
The printer does not detect the presence of the Fuser.
W
arn
i
ng
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
Applicable Chain Link
■ Chain Link 010-317: Insert Fuser
Initial Actions
■ Ensure that the Fuser latches are fully locked.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Fuser, PL6.1.10
■ MCU Board, PL9.1.20
■ Fuser Harness, PL6.1.11
■ “Map 1 - Electrical and Drive” on
page 10-10
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Fuser” on page 10-46
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Fuser for correct installation. Go to step 3. Reseat the
Fuser. Go to
step 2.
2 Does the error still occur? Go to step 3. Complete.
3 Check the wiring harness connectors P/J17
and P/J171 between the MCU Board and
the Fuser. Are the connectors securely
connected?
Go to step 4. Reconnect
the
connectors.
Go to step 4.
4 Check the Fuser Harness for continuity.
1. Disconnect P/J17 and P/J171.
2. Check continuity between P/J17 <=> P/
J171.
Go to step 5. Replace the
Fuser
Harness.
