Phaser 6180 Color Laser Printer Service Manual 2-9
Theory of Operation
Transfer (Drum ---> Paper)
Toner image formed on the Drum surface is transferred onto the surface of the
paper. The toner is transferred onto the paper in the order of Y, M, C, and K.
s6180-140
Drum Surface
(Black Toner Image)
Drum Surface
(Cyan Toner Image)
Drum Surface
(Magenta Toner Image)
Drum Surface
(Yellow Toner Image)
Paper
Black
Toner Image
Cyan
Toner Image
Magenta
Toner Image
Yellow
Toner Image
