1-20 Phaser 6180 Color Laser Printer Service Manual
General Information
Mounting Surface Specifications
These specifications apply to any printer used as a table-top printer.
1. In order to function properly, the printer must be placed on a surface with
the following minimum dimensions.
2. Mounting surface flatness must be within the specified range.
60 cm60 cm
121.5 cm
10 cm
10 cm
13 cm
s6180-264
Right Hand Side
s6180-263
5mm Max
