8-2 Phaser 6180 Color Laser Printer Service Manual
Service Parts Disassembly
Overview
This section contains the removal procedures for field-replaceable parts of the
printer listed in the Parts List. In most cases, the replacement procedure is
simply the reverse of the removal procedure. In some instances, additional
steps are necessary and are provided for replacement of the parts. For
specific assemblies and parts, refer to the “Parts List” in Section 9.
The procedures are organized by the consumer replacement parts and
functions of the printer.
■ Always use the correct type and size screw. Using the wrong screw can
damage tapped holes. Do not use excessive force to remove or install
either a screw or a printer part. (page 8-6)
■ Transfer Unit (page 8-7)
■ Print Cartridge (C/M/Y/K) (page 8-9)
■ Fuser (page 8-10)
■ Covers (page 8-11)
■ Paper Tray (page 8-24)
■ Paper Feeder (page 8-35)
■ Xerographics (page 8-50)
■ Exit Chute (page 8-63)
■ Frame (page 8-65)
■ Drive (page 8-73)
■ Electrical (page 8-79)
■ Duplex Unit (page 8-94)
■ Optional 550-Sheet Feeder (page 8-96)
