Phaser 6180 Color Laser Printer Service Manual 73
Service Parts Disassembly
Drive
Main Drive (PL8.1.2)
1. Remove the Rear Cover (page 8-11).
2. Remove the Right Side Cover (page 8-12).
3. Remove the Left Side Cover (page 8-13).
4. Remove the Top Cover (page 8-14).
5. Remove the Interlock Harness (page 8-80).
6. Remove 2 screws (10 mm) securing the Fuser Bracket (PL6.1.12) to the
printer.
Caution
DO NOT separate the Fuser Bracket and the printer too far apart,
because they are connected by a wiring harness.
7. Remove the Fuser Bracket.
8. Release the Main Drive wiring harness from the Main Drive Duct
(PL8.1.9).
9. Remove 1 screw (10 mm) securing the Main Drive Duct to the printer.
10. Release the notch of the Main Drive Duct and push the Main Drive Duct
toward the back. Remove the Main Drive Duct.
11. Disconnect the following 4 connectors:
■ Main Motor - P/J211 (Main Motor), Sub Motor - P/J221, Developer
Motor - P/J222
■ Exit Clutch: P/J2761 on the Main Drive.
