Phaser 6180 Color Laser Printer Service Manual 85
Service Parts Disassembly
Power Switch (PL9.1.13)
1. Remove the Rear Cover (page 8-11).
2. Remove the Right Side Cover (page 8-12).
3. Disconnect the Power Switch connector P/J481.
4. Release the hook and remove the Power Switch.
s6180-035
P/J481
To Next Page
