Xerox Phaser 6180 - Parts of the Printer; Front and Side Views

1-4 Phaser 6180 Color Laser Printer Service Manual
General Information
Parts of the Printer
Front and Side Views
1. Tray 2
2. Tray 3
3. Tray 1 (MPT)
4. Front Cover (Door A)
5. Control Panel
6. Output Tray
7. Extender Cover
8. Top Cover
9. Front Cover Release Button
10. Power Switch
1
2
3
4
5
6
7
10
9
8
s6180-346
