Phaser 6180 Color Laser Printer Service Manual 3-33
Error Messages and Codes
5 Check the resistance of temperature sensor
in the Fuser.
1. Remove the Fuser.
2. Disconnect P/J171.
3. Check continuity between:
■ P/J171-8 <=> P/J171-7
■ P/J171-4 <=> P/J171-6
■ P/J171-4 <=> P/J171-5
Replace the
MCU Board
(page 8-87).
Replace the
Fuser
(page 8-10).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
