Phaser 6180 Color Laser Printer Service Manual 3-17
Error Messages and Codes
32 Check the Tray 3 Feeder Board signal.
1. Disconnect P/J27 on the MCU
Board.
2. Is there +24 V across ground <=>
J27-B4/J27-B5 when the Interlock
Switch is activated?
Replace the Tray
3 Feeder
(page 8-102).
Replace the
MCU Board
(page 8-87).
33 Check the following for evidence of
fault or damage:
■ Turn Roll, PL3.2.32
■ Feed Roll, PL12.1.9
Go to step 34. Replace the
defective
part(s). If the
Turn Roll is
damaged,
replace the Tray
3 Feeder
(page 8-102).
34 Replace the Optional 550-Sheet Feeder
(page 8-96). Does the error still
occur?
Replace the
MCU Board
(page 8-87).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
