Phaser 6180 Color Laser Printer Service Manual 3-87
Error Messages and Codes
7 Check the Right Side Harness for
continuity.
1. Disconnect P/J22 and P/J221.
2. Check continuity between P/J22 <=>
P/J221.
Go to step 8. Replace the
Right Side
Harness.
8 Check the Main Drive signal.
1. Disconnect P/J22 from the MCU
Board.
2. Are there +24 V across ground <=>
J22-A2/J22-A4 when the Interlock
Switch is activated?
Replace the
Main Drive
(page 8-73).
Replace the
MCU Board
(page 8-87).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
