Phaser 6180 Color Laser Printer Service Manual 3-97
Error Messages and Codes
6 Check the Front Cover Harness for
continuity.
1. Disconnect P/J272 and P/J2720.
2. Check continuity between P/J272
<=> P/J2720.
Go to step 7. Replace the
Front Cover
Harness.
7 Check the Right Side Harness for
continuity.
1. Disconnect P/J272 and P/J27.
2. Check continuity between P/J272
<=> P/J27.
Go to step 8. Replace the
Right Side
Harness.
8 Replace the Duplex Unit (page 8-94).
Does the error still occur?
Replace the
MCU Board
(page 8-87).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
