5-38 Phaser 6180 Color Laser Printer Service Manual
Print-Quality Troubleshooting
W
arn
i
ng
Ensure to wait for the Fuser to cool down before starting the procedure.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the black line’s regular intervals.
Are there any black lines on the page?
Refer to “The
following table
lists the print-
quality defect
corrective
procedure, their
definition, and
the page where
each procedure
is provided.” on
page 23.
Go to step 2.
2 Check the Print Cartridge (C/M/Y/K)
for damages. Is the Print Cartridge
damaged?
Go to step 3. Replace the
Print Cartridge
(page 8-9).
3 Check the Transfer Unit. Are there any
damages on the Transfer Unit surface?
Replace the
Transfer Unit
(page 8-7).
Go to step 4.
4 Check the Transfer Unit for correct
installation. Reseat the Transfer Unit.
Does the image quality improve?
Complete. Go to step 5.
5 Check the Fuser for correct
installation. Reseat the Fuser.
Does the image quality improve?
Complete. Go to step 6.
6 Check the paper path. Are there any
toner contaminations on the paper
path?
Complete. Go to step 7.
7 Check the wiring harness connectors
P/J12 and P/J151 between the Laser
Unit and the MCU Board.
Are the connectors securely
connected?
Go to step 8. Reconnect the
connectors.
Go to step 8.
8 Check the Print Cartridge (C/M/Y/K)
for correct installation. Reseat the
Print Cartridge.
Does the image quality improve?
Complete. Go to step 9.
9 Check the MCU Board for correct
installation. Reseat the MCU Board.
Does the image quality improve?
Complete. Go to step 10.
10 Check the Image Processor Board for
correct installation. Reseat the Image
Processor Board.
Does the image quality improve?
Complete. Go to step 11.
