6-4 Phaser 6180 Color Laser Printer Service Manual
Adjustments and Calibrations
Manual Adjustment
Use the adjustment information in the following table to perform Color
Registration procedure.
Caution
After printing the Color Registration Correction Chart, DO NOT turn Off
the printer until the printer motor has stopped running.
1. From the Control Panel, press the Menu button.
2. Press the Up Arrow or Down Arrow button to find Admin Menu. Press
the OK button.
3. Press the Up Arrow or Down Arrow button to find Maintenance Mode.
Press the OK button.
4. Press the Up Arrow or Down Arrow button to find Adjust Color Regi.
Press the OK button.
5. Press the Up Arrow or Down Arrow button to find Enter Number. Press
the OK button.
6. Use the Up Arrow or Down Arrow button to enter the values and the Left
Arrow or Right Arrow button to move from Y to M to C.
7. Press the OK button to save the data. The Enter Number menu is
displayed.
8. Press the Up Arrow and Down Arrow buttons simultaneously to access
the Color Regi Chart menu. Press the OK button to print the Color Regi
Chart.
9. The Color Registration adjustment is complete when the straightest Y
(yellow), M (magenta), and C (cyan) lines are next to the “0” line.
o
e
If “0” is not next the straightest lines, determine and adjust the values
again.
Color Registration Adjustment
Color
Range Default
Yellow -9 to +9 0
Magenta -9 to +9 0
Cyan -9 to +9 0
