36 Phaser 6180 Color Laser Printer Service Manual
Service Parts Disassembly
5. Disconnect the Tray 1 (MPT) Feed Solenoid connector P/J236.
6. Release the Feed Solenoid wiring harness from the Solenoid Duct
(PL3.1.2) and the Drive Duct (PL8.1.8).
7. Remove 1 screw (8 mm) securing the Feed Solenoid to the printer.
8. Remove the Tray 1 (MPT) Feed Solenoid.
s6180-023
P/J236
