Phaser 6180 Color Laser Printer Service Manual 9-7
Parts List
Parts List 1.2 Covers (2 of 2)
ID No. Name/Description Part Number
1. Kit Cover Assy Front (with 2-9, 11-15, 18-23, 36) 675K47129
2. Plate Latch
3. Spring Latch
4. Latch Front
5. Cover Harness
6. Button Top
7. Contact Front
8. Shaft Pivot (Pin Kit) 675K47432
9. Cover Front Assy
10. -----
11. Harness Assy Front Cover (J272-P2720, P2721) - (Harness Kit) 604K38541
12. Harness Assy Front Cover Earth 1 (T4321-T43210)
13. Harness Assy Drawer Earth (T4321-T43210)
14. Holder Drawer
15. Harness Assy Operation Panel (J220-P2900) - (Harness Kit) 604K38541
16. Operator Panel (Control Panel) 848K01182
17. Pin Pivot (Pin Kit) 675K47432
18. Shaft Lever
19. Plate Pivot
20. Lever MPT 1
21. Spring Lever MPT
22. Spring Lever Link
23. Lever MPT 2
24. Cover Assy MPT (with 25-29, 35) 848K02012
25. Link Assy MPT Left
26. Tray Assy MPT Base
27. Link Assy MPT Right
28. Tray MPT
29. Cover MPT (Tray 1 Cover/Door A)
30. Shaft Pivot MPT (Pin Kit) 675K47432
31. Harness Assy Front Cover Earth 2 (T4322-T43221)
32. Harness Assy ESS (J29-J2900) - (Harness Kit) 604K38541
33. Clamp RLWT-4V0 (not shown)
34. -----
35. Spring Tray
36. Spring
98. Kit Pin BKY (with 8, 17, 30 - 2pcs each) 675K47432
