Phaser 6180 Color Laser Printer Service Manual 9-13
Parts List
Parts List 3.1 Paper Feeder (1 of 2)
ID No. Name/Description Part Number
1. Clamp
2. Duct MPT Solenoid
3. Kit Solenoid Feed MPT (with 4, 5) 675K35590
4. Spring Feed MPT
5. Gear MPT
6. Bearing Earth
7. CAM MPT Right
8. Roll Assy MPT (with 7, 9-12, 18) 059K43961
9. Roll Core MPT
10. Kit Roll Assy Feed MPT (with tech sheet) 675K47380
11. Pin Dowel
12. Shaft MPT
13. Bearing
14. Chute MPT
15. Sensor Photo (Tray 1 No Paper Sensor) 930W00113
16. Cover Sensor 802E89292
17. Harness Assy MPT NPP (J275-J2751) - (Harness Kit) 604K38550
18. CAM MPT Left
19. Clutch Assy PH Regi
20. Clutch Assy PH Feeder
To Next Page
