Phaser 6180 Color Laser Printer Service Manual 9-29
Parts List
Parts List 10.1 Wiring Harness
ID No. Name/Description Part Number
1. -----
2. -----
3. -----
4. Harness Assy Humidity (J26-J261) - (Harness Kit) 604K38560
5. -----
6. -----
7. Harness Assy ESS (J10-J101) - (Harness Kit) 604K38560
8. Harness Assy Video (J11-J111) - (Harness Kit) 604K38560
9. Harness Assy TNR SNR (J19-J191, J192, J193, J194) - (Harness Kit) 604K38560
10. -----
11. -----
12. -----
13. Harness Assy CRUM (J31-J311, J312, J313, J314) - (Harness Kit) 604K38560
14. Harness Assy Exit CLT (J276-J2761) - (Harness Kit) 604K38550
15. Harness Assy Right Side (J21, J22, J23, J25, J27-J211, J221, J222, J231, J232, P233,
P234, P235, P236, J251, P272, P273, J274, P275, P276)
962K42112
16. Harness Assy LV Top (J14, J15, J18, J401-J141, P181, P182, P183, P184, J40, J501,
J502)
962K42101
17. Harness Assy RLY (J504-J5401)
