Phaser 6180 Color Laser Printer Service Manual 10-17
Plug/Jack and Wiring Diagrams
Denotes the control and its outline in the Board.
Denotes a connection between parts with
harness or wires, attached with signal name/
contents.
Denotes the function, and logic value of the
signal to operate the function (Low: L, High: H).
The given voltage is for signal in high status.
The arrow indicates the direction of signal.
Denotes the function, and logic value of the
signal when the function operated (Low: L, High:
H).
The given voltage is for signal in high status.
The arrow indicates the direction of signal.
Denotes a connection between wires.
Denotes a Clutch or Solenoid.
Denotes a Motor.
Symbol
Description
Control
s6180-473
DEVE_A
s6180-474
CLUTCH ON(L)+24V
s6180-475
EXIT SENSED(L)+3.3VDC
s6180-476
s6180-477
s6180-464
M
s6180-465
