Phaser 6180 Color Laser Printer Service Manual 10-35
Plug/Jack and Wiring Diagrams
Signal Line Name Description
MAIN MOT ON Drives control signal of the Main Motor.
MAIN MOT ALARM
MAIN MOT LO
MAIN MOT CW/CCW
SUB MOT ON Drives control signal of the Sub Motor.
SUB MOT ALARM
SUB MOT CLK
SUB MOT LO
SUB MOT BRAKE
DEVE MOT ON Drives control signal of the Developer Motor.
DEVE MOT ALARM
DEVE MOT CLK
DEVE MOT LO
DEVE MOT BRAKE
EXIT CL ON (L) +24 VDC On/Off signal of the Exit Clutch.
