Xerox Phaser 6280 Service Manual

2-64 Phaser 6280 Color Laser Printer Service Manual
Theory of Operation
Main Drive Assembly (Color - moving parts)
s6280-106
Main Motor
Sub Motor
Drum Gear (C)
Mag Roller Gear (C)
Deve Idle Gear (C)
Auger Gear (C)
Gear D2
Gear K3
Cam C
Flange D3
Gear D3 In
Gear D3 Out
Drum Gear (Y)
Magnet Roller Gear (Y)
Deve Idle Gear (Y)
Auger Gear (Y)
Drum Gear (M)
Mag Roller Gear (M)
Deve Idle Gear (M)
Auger Gear (M)
K Mode
Switching Solenoid
Gear C
Cam C
Gear D3 In
Gear D3 Out
K Drive
Assembly
Main Drive Assembly
Front
Drum Gear (K)
[ Drum (K) ]
Gear Drive
[ Belt ]
Magnet Roller Gear (K)
[ Deve Magnet Roller (K) ]
Deve Idle Gear (K)
Auger Gear (K)
[ Admix Auger (K) ]
Auger Gear (K)
[ Supply Auger (K) ]
: Indicates The Engagement Of Gears.
[ Name Of Moving Parts ][ Full Color Mode ]
Cartridge
Assy (K)
Cartridge
Assy (C)
Cartridge
Assy (M)
Cartridge
Assy (Y)
