Xerox Phaser 6280 Service Manual

Phaser 6280 Color Laser Printer Service Manual 3-29
Error Messages and Codes
7 Check the Exit Sensor signal.
1.Measure the voltage across ground
<=> J17-3 pin on the MCU Board.
2.Does the voltage change when the
Actuator of the Exit Sensor is
activated?
Replace the
MCU Board
(
page 8-86).
Replace the
Fuser Unit
(
page 8-11).
8 1. Perform the Regi Clutch test
(page 4-51): Service Mode >
Engine Diag > Motor Test > Regi
Clutch.
2.Does the Clutch operate properly?
Replace the Regi
Clutch
(
page 8-40).
Replace the
MCU Board
(
page 8-86).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
