3-38 Phaser 6280 Color Laser Printer Service Manual
Error Messages and Codes
19 Check the Duplex Motor for continuity.
1.Disconnect P/J429 from the Duplex
Board.
2.Is there +24 V across ground <=>
J429-2 pin on the Duplex Board?
Replace the
Duplex Unit
(
page 8-99).
Perform steps
10 through 14.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
