Xerox Phaser 6280 Service Manual

4-20 Phaser 6280 Color Laser Printer Service Manual
General Troubleshooting
Print Counter Print Counter
■ Color Print
■ n
■ B/W Print
■ n
■ Total Print
■ n
■ Color Backup
■ n
■ B/W Backup
■ n
■ Total Backup
■ n
■ Color Error
■ n
■ B/W Error
■ n
Menu Buttons
<Press the Up or Down
button to move from one
item to another>
<Press the Cancel button
to move one/two level(s)
up the menu>
<Press the Set button to
run the test>
Operates the print counter.
Copy Counter
MtoB
CopyCounter MtoB
■ OK?
■ Processing
■ Copied
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
run the test>
Copies the values from Master NVRAM
to Backup NVRAM.
■ Device-specific information called *
■ “Personal info” in the first 128 Byte
■ PV counter master
■ Printer counter master
Copy Counter
BtoM
CopyCounter BtoM
■ OK?
■ Processing
■ Copied
<Press the Cancel button
to move one level up the
menu>
<Press the Set button to
run the test>
Copies the values from Backup NVRAM
to Master NVRAM.
■ Device-specific information called
“Personal info” in the first 128 Byte
■ PV counter backup
■ Printer counter backup
Service Diagnostic Test Table (continued)
Test Control Panel Display Test Description

Xerox Phaser 6280 Specifications

General

Print Resolution	Up to 600 x 600 x 4 dpi
Processor	400 MHz
Operating System Compatibility	Windows, Mac OS, Linux
Print Technology	Laser
Monthly Duty Cycle	70, 000 pages
Memory	256 MB (standard)
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	A4, A5, B5, Executive, Legal, Letter
Maximum Paper Size	8.5 x 14 inches
