4-24 Phaser 6280 Color Laser Printer Service Manual
General Troubleshooting
Fast Scan KtoY Fast Scan KtoY
■ -30 *
■ :
■ 30 *
Fast Scan KtoC Fast Scan KtoC
■ -30 *
■ :
■ 30 *
Fast Scan
Tray 1 (MPT)
Fast Scan MPT
■ -30 *
■ :
■ 30 *
Fast Scan
Tray 2
Fast Scan Tray 2
■ -30 *
■ :
■ 30 *
Fast Scan
Tray 3
Fast Scan Tray 3
■ -30 *
■ :
■ 30 *
Fast Scan
Duplex
Fast Scan Duplex
■ -30 *
■ :
■ 30 *
Fast Scan 2
KtoM
Fast Scan 2 KtoM
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoY
Fast Scan 2 KtoY
■ -1 *
■ :
■ 2 *
Fast Scan 2
KtoC
Fast Scan 2 KtoC
■ -1 *
■ :
■ 2 *
Life Y Toner Life Y Toner
■ 0
Reads life counter of the yellow toner.
Life M Toner Life M Toner
■ 0
Reads life counter of the magenta
toner.
Life C Toner Life C Toner
■ 0
Reads life counter of the cyan toner.
Life K Toner Life K Toner
■ 0
Reads life counter of the black toner.
Service Diagnostic Test Table (continued)
Test Control Panel Display Test Description
