Phaser 6280 Color Laser Printer Service Manual 4-23
General Troubleshooting
Menu Buttons
<Press the Up or Down
button to move from one
item to another or
change the value>
<Press the Cancel button
to move to one/two
level(s) up the menu
without saving the value>
<Press the Set button to
run the test or the value
in NVM and move one
level up the menu>
Note: After the setting has been
changed, the “*” at the right end
disappears.
Sets registration in the paper feeding
direction.
Note: When the value is minimum or
maximum, pressing the Up or Down
button does not change the value.
Slow Scan KtoP Slow Scan KtoP
■ -128 *
■ :
■ 127 *
Adjusts the registration in the paper
feeding direction.
Slow Scan
600M
Slow Scan 600M
■ -30 *
■ :
■ 30 *
Slow Scan
600Y
Slow Scan 600Y
■ -30 *
■ :
■ 30 *
Slow Scan
600C
Slow Scan 600C
■ -30 *
■ :
■ 30 *
Slow Scan
1200M
Slow Scan 1200M
■ -60 *
■ :
■ 60 *
Slow Scan
1200Y
Slow Scan 1200Y
■ -60 *
■ :
■ 60 *
Slow Scan
1200C
Slow Scan 1200C
■ -60 *
■ :
■ 60 *
Fast Scan KtoM Fast Scan KtoM
■ -30 *
■ :
■ 30 *
Sets the registration in the scanning
direction for Tray 1 (MPT), Tray 2, Tray
3, and Duplex Unit.
Service Diagnostic Test Table (continued)
Test Control Panel Display Test Description
To Next Page
Loading...
