Phaser 6280 Color Laser Printer Service Manual 4-63
General Troubleshooting
Duplex Fan
When performing this procedure, remove and cover the Print Cartridges
to avoid exposure to light.
1. Enter the Service Diagnostic menu (page 4-5).
2. Open the Front Cover.
3. Remove the Transfer Unit (page 8-8).
4. Remove the Print Cartridges (page 8-10).
5. Use a paper clip to secure the Interlock Switch.
6. Perform the Duplex Fan test: Engine Diag > Motor Test > Duplex Fan.
7. Verify that the Fan is operating.
8. Press the Cancel button to stop the Duplex Fan test.
9. Remove the paper clip from the Interlock Switch.
To Next Page
