Phaser 6280 Color Laser Printer Service Manual 9-17
Parts List
Parts List 3.2 Paper Feeder (2 of 2)
ID No. Name/Description Part Number
1.
Feeder Assy (with 2, 11, 21, 25-28, 30, 32-34, 37, 42, 51-53, 55, 59, 61, 62) 675K74270
2. Chute Assy Regi (with 3-21)
3. Bracket NIP
4. Spring Regi Left
5. Spring Regi Right
6. Roll Regi Metal
7. Roll Regi Rubber
8. Film Inlet Left
9. Gear Regi Metal
10. Gear Regi Rubber
11. Bearing Regi
12. Chute Regi
13. Actuator A
14. Spring Regi Sensor A
15. Actuator B
16. Spring Regi Sensor B
17. Cover Actuator
18. Chute Separator BTM
19. Clamp Mini-Saddle
20. Clamp
21. Bearing Regi E
22. -----
23. Clutch Assy PH 121K37151
24. Clutch Assy PH Feed 121K37151
25. Clutch Assy PH Turn 121K37151
26. Bearing Nudger
27. Spring Earth
28. Chute Assy Regi Upper (with 29, 30)
29. Chute Regi Upper
30. Sensor Photo (Regi Sensor, Tray No Paper Sensor) 930W00113
31. -----
32. Roll Assy Turn
33. Chute Assy Top (with 35, 36)
34. Holder No Sensor
35. Chute Assy Separator
36. Clamp
37. Harness Assy Regi Sensor (J292-J2921, J2922) - (Harness Kit) 675K74380
38. -----
39. -----
40. -----
To Next Page
